YJJ PE175BFA Cold Light Source Endoscope Xenon Lamp Storz STORZ Laparoscopic Endoscope Xenon Lamp

Product Description:

YJJ PE175BFA Cold Light Source Endoscope Xenon Lamp Storz STORZ Laparoscopic Endoscope Xenon Lamp

Features:

I. Electrical and Optical Parameters

‌Rated Power‌

175W, specially designed for high-precision endoscopic surgeries, providing high-intensity cold light source illumination .

‌Voltage and Current‌

Operating Voltage: 12.5V (DC), allowable range 11 - 14V ;

Operating Current: 14A (DC), allowable range 12 - 16A ;

Starting requires high-voltage pulse: 23,000V .

‌Optical Performance‌

Luminous Flux: 2200lm, close to daylight color temperature (5600K - 5800K) 27;

Ultra-high color rendering, ensuring true colors and clear details in the surgical field .

II. Physical and Compatibility

‌Compatible Systems‌

Compatible with ‌STORZ Laparoscope‌ (Model 615 B/C/XE), ‌Olympus CLV Series‌, Fujinon, Pantex, etc. mainstream endoscopic cold light source systems ;

Standardized interface, convenient replacement (requires applying conductive silicone grease) .

‌Size and Heat Dissipation‌

Lamp Body Length: 87mm ;

Built-in efficient heat dissipation structure, maximum temperature resistance ‌150°C‌ 46.

️ III. Lifespan and Stability

‌Effective Lifespan‌: 500 hours, supporting long-term surgeries without brightness attenuation ;

‌Interference Resistance‌: No flicker or brightness fluctuations during operation, avoiding frequent parameter adjustments during surgery ;

‌Industrial-grade Sealing‌: Sapphire transparent mirror surface + ceramic base, dust-proof and shock-proof
